2.4-inch Display Door Access Control Touch Keypad 125KHz Compatible

UHPPOTE RFID ACCESS CONTROL TERMINAL HBK-A04T , 2.4-inch Display Door Access Control Touch Keypad 125khz Compatible with WiFi Tuya
INTRODUCTION
The 2.4" TFT-LCD display area contains 320 x (RGB) x 240 pixels and can display up to 262K colors.
This RFID card access control unit controls single door.
Full programming from the keypad.
The keypad numbers are easily to be seen at night or in dark envoriment thanks to the backlighting, and the backlight mode can be set ON/OFF/Auto cording to the need.
It uses high performance 32-bit MCU to ensure stable performance, and low-power circuit makes the service life longer.
Power relay with 10A switching capacity provides an excellent switching performance for electric locks.
It is widely used in factories, houses, residential quarters, offices, mechanical and electrical control equipment and so on. FEATURES

Supports Card, PIN, Card + PIN, Card or PIN.

Can be used as standalone keypad.

Adjustable door delay time.

Very low power consumption.

Lock output current short circuit protection.

Adopt the switch mode power supply (SMPS) solution.

With bell function, supports external bell.

The sounds of built-in buzzer can be set ON or OFF.

The keypad backlight mode can be set. (ON/OFF/Auto)

The screen sleep mode can be set. (ON/OFF)

Tuya SMART APP

Smartphone remote control from any where, anytime

Phone APP remotely control the device and manage users from anywhere

View door opening records

Work with Alexa or Google and control the smart lock with voice

The smart scene allows users to use one device to automatically trigger ON/OFF one or more devices.

The device only supports 2.4GHz WiFi rounter and 5GHz router is not avaliable.
